Designed for simple multicolor fluorescence imaging and routine experiments, the IXplore™ Standard microscope system is easy to operate and capable of producing excellent, publication-quality images. A range of encoded unit options makes it easy to get accurate and reproducible results.
Designed for simple multicolor fluorescence imaging and routine experiments, the IXplore? Standard microscope system is easy to operate and capable of producing excellent, publication-quality images. A range of encoded unit options makes it easy to get accurate and reproducible results.
Accuracy and Repeatability
Smooth Tracking at High Magnification
The IX3-SVR manual stage features a smooth positioning system that enables cells to be easily tracked, even at high magnifications.
Observation limit settings immobilize the stage and help maintain its position, including during reagent applications, even if the stage is inadvertently touched.
Using the stage's fixing plate and positioning screws, you can remove a 35 mm dish from the stage, transfer it to an incubator, and return it to its exact previous position.
Easy K?ehler Illumination
The condenser can be moved and easily reset to K?hler illumination using the conveniently located condenser lock and control knobs.
Encoded Units (Optional Peripherals)
A Cost-Effective Way to Upgrade to a Smart Microscope
A wide range of optional units are available for upgrades, including:
8-position motorized or encoded fluorescence mirror turrets
6-position motorized or encoded nosepiece
Motorized long working distance universal condenser
Filter wheels and shutters
Ease of Use
One Camera for Multiple Applications
The DP75 digital microscope camera is a high-performance, multi-application imaging tool that makes it easy to capture high-resolution brightfield or fluorescence images using a single camera.
High Contrast under Bright Conditions
The unit is designed specifically for fluorescence observation. It efficiently blocks out room light, enhances the contrast of fluorescence, and enables clear fluorescence observation under bright conditions.
Intuitive Operation with cellSens? Imaging Software
Our cellSens software is easy to use, powerful, and flexible. Featuring a modular design, the software can be tailored to your budget and imaging applications. This enables the software to grow and adapt to meet evolving research needs.
 |  |
Simplify Your Workflow
Objectives for Observation Using Plastic Vessels
LUCPLFLN series objectives, and in particular the UCPLFLN20XPH (NA 0.7), are well-suited for observation using plastic dishes. The objectives enable high-resolution observation of the cell proliferation process and deliver improved contrast across a wide area. This gives you the flexibility to image through plastic-bottom dishes in addition to glass.
*Image: iPS-cell expressing Nanog reporter (GFP) Image data courtesy of: Tomonobu Watanabe, Ph.D. Laboratory for Comprehensive Bioimaging, RIKEN Quantitative Biology Center
.jpg "Microscope") | .jpg "Microscope") |  |
High-Quality Imaging
High Signal-to-Noise Fluorescence Mirror Units for Efficient Signal Detection
All fluorescence mirror units feature filters treated with a specially developed coating that absorbs more than 99% of stray light. This reduction in reflections and high transmittance of the mirror units helps provide fluorescence images with a high signal-to-noise ratio.
.jpg "Microscope") |  |
